• Conical tapered spring on warm grey backdrop — Daichi Springs
1 1

Tapered Spring

Tapered Spring

A compression spring with a varying outer diameter — wider at one end, narrower at the other. Compresses to less than the wire diameter at full collapse.

A tapered (or conical) spring solves a common problem: when fully compressed, a standard cylindrical spring is at least as tall as its solid height. A tapered spring can collapse flat — coil-on-coil — saving stack height and reducing buckling.

Used wherever low solid height matters: battery contact springs, retractable mechanisms, low-profile assemblies.

Specifications

Wire diameter 0.1mm – 6mm
OD range 5:1 ratio max (large end : small end)
Free length up to 200mm
Solid height as low as wire diameter
Materials Stainless spring steel, high-carbon spring steel
Lead time Production runs 1–3 weeks · walk-in single-piece custom often within an hour
MOQ None — single piece available

Common applications

  • Battery contact springs in electronics
  • Retractable pen mechanisms
  • Low-stack-height suspension components
  • Buckle and clip assemblies

Get a quote for this tapered spring →

Get a quote for this tapered spring → or call +63 917 144 9976

Materials & finishes

Stainless spring steel and high-carbon spring steel for most spring types. Chrome silicon and chrome vanadium for die-spring grades. Polyurethane elastomer for urethane springs. Finishes available: zinc plating, black oxide, phosphate, passivated stainless.

Dimensions & tolerances

Wire diameter range: 0.1mm – 10mm. Tolerance: ±0.05mm wire, ±1% free length, ±10% load. Squareness: 3° or less. Custom geometries to drawing — send a sample or a sketch.

Lead time & ordering

Walk-in single-piece custom: often within an hour at our Valenzuela factory for standard geometries. Stock items: 2–5 days. Production runs: 1–3 weeks. No minimum order — single piece available.

QC & documentation

Every batch is sample-tested before pack-out. Mill certificates, dimensional reports, and full material traceability available on request — at no extra charge for production runs above 500 pieces.

View full details

  • Have a sample?

    Bring it to our factory in Valenzuela. Walk-ins welcome Mon–Sat 08:30–16:00 — we'll quote on the spot for standard work.

    Get directions

  • 2–5 days standard

    Most stock springs ship in 2–5 days. Custom runs in 1–3 weeks. Same-day pickup at our Valenzuela factory available.

  • Material certs included

    Mill certificates, dimensional reports, and material traceability documentation provided at no charge for production runs above 500 pieces.
